Building a Windows 11 gold template

1. How it fits together

You build and keep two things in Proxmox:

Each new version (v2, v3…) is a fresh copy of the updated master. Old templates stay until no pool uses them.

When SDE VDI creates a desktop from the template, it:

1. Makes a linked clone, named after the pool (for example W11-OFF-007).
2. Starts it. Windows finishes setup on its own and comes up with a new security identity (SID) and a temporary random name.
3. Uses the QEMU guest agent to rename it and, where Active Directory is configured, join it to the domain. It then restarts.
4. Waits for Remote Desktop to answer, then marks it as a spare desktop.

2. Before you start

3. Choose where the template lives

Linked clones are created on the same storage as the template. Pick the storage first, because it decides which nodes can run the pool:

4. Create the master VM

In the Proxmox web UI, select Create VM and use these settings. Anything not listed can stay at its default.

Don't start the VM from the summary screen yet. Check that Hardware lists two CD drives (Windows and VirtIO), an EFI disk and a TPM state disk.

Or create it with one command

Quicker and harder to get wrong. In the Shell of the node the template will live on, first check the ISO file names (ls /var/lib/vz/template/iso/) and the bridge name (node → System → Network, usually vmbr0), then run, swapping in your ISO name, bridge and storage:

qm create 8001 --name w11-office-master --ostype win11 \
  --machine q35 --bios ovmf \
  --efidisk0 datastore01:1,efitype=4m,pre-enrolled-keys=1 \
  --tpmstate0 datastore01:1,version=v2.0 \
  --scsihw virtio-scsi-single --scsi0 datastore01:64,iothread=1,discard=on,ssd=1 \
  --cpu x86-64-v2-AES --cores 4 --memory 8192 --balloon 0 \
  --net0 virtio,bridge=vmbr0 --agent enabled=1 \
  --ide2 local:iso/YOUR-WIN11.iso,media=cdrom \
  --ide0 local:iso/virtio-win.iso,media=cdrom \
  --boot order='ide2;scsi0'

--balloon 0 turns memory ballooning off so Windows sees all of its memory. On a cluster short of memory, --memory 4096 is the Windows 11 minimum and fine for testing.

5. Install Windows

1. Start the VM and open the Console. Press a key when you see Press any key to boot from CD or DVD. If you miss it, reset the VM and try again.
2. Choose your language, English (United Kingdom) time format and the United Kingdom keyboard, then select Install.
3. At Select location to install Windows 11 no disk is listed yet. Select Load driver → Browse, open the VirtIO CD, and choose vioscsi\w11\amd64. Install the Red Hat VirtIO SCSI pass-through controller.
4. Select Load driver again and choose NetKVM\w11\amd64. This adds the network driver now, so Windows has a network during setup.
5. Select the unallocated disk and continue. Windows installs and restarts a few times.
6. In the out-of-box screens, choose region United Kingdom and keyboard United Kingdom.
7. When it asks for a Microsoft account, select Sign-in options → Domain join instead. This creates a local account.
   • If that option is missing, press Shift+F10 and run start ms-cxh:localonly.
8. Create the local administrator vdiadmin with a strong password. Record the password in the password manager.
9. Turn every privacy option off and finish setup.

6. Configure Windows

Sign in as vdiadmin. Run the commands in an elevated PowerShell window (right-click Start → Terminal (Admin)).

6.1 Install the VirtIO guest tools and QEMU guest agent

1. In File Explorer, open the VirtIO CD and run virtio-win-guest-tools.exe. Accept the defaults. It installs all VirtIO drivers and the QEMU guest agent.
2. Check that the agent is running:

   Get-Service QEMU-GA

   It should show Running.
3. In Proxmox, open the VM's Summary. After a minute, IPs shows the VM's address instead of Guest Agent not running.

6.2 Stop Store apps updating themselves

Store apps that update for one user break sysprep later, so do this before running Windows Update.

New-Item -Path 'HKLM:\SOFTWARE\Policies\Microsoft\WindowsStore' -Force | Out-Null
Set-ItemProperty -Path 'HKLM:\SOFTWARE\Policies\Microsoft\WindowsStore' -Name AutoDownload -Value 2 -Type DWord

6.3 Windows Update

Open Settings → Windows Update and install everything. Restart and check again until no updates are left, including optional driver updates you want in the image.

6.4 Remote Desktop

# Allow Remote Desktop with Network Level Authentication, and open the firewall
Set-ItemProperty 'HKLM:\System\CurrentControlSet\Control\Terminal Server' -Name fDenyTSConnections -Value 0
Set-ItemProperty 'HKLM:\System\CurrentControlSet\Control\Terminal Server\WinStations\RDP-Tcp' -Name UserAuthentication -Value 1
Enable-NetFirewallRule -DisplayGroup 'Remote Desktop'

6.5 Test user (dev only, no Active Directory)

Dev desktops aren't joined to a domain, so users sign in with a local account built into the image. Skip this in live, where a domain group is given Remote Desktop rights by Group Policy.

$pw = Read-Host -AsSecureString 'Password for vdiuser'
New-LocalUser -Name vdiuser -Password $pw -PasswordNeverExpires -FullName 'VDI test user'
Add-LocalGroupMember -Group 'Remote Desktop Users' -Member vdiuser

6.6 Power settings

A pool desktop must never sleep or hibernate, or it drops out of the pool.

powercfg /hibernate off
powercfg /change standby-timeout-ac 0
powercfg /change monitor-timeout-ac 0

6.7 Session time limits

SDE VDI only recycles a desktop once the user has signed out. These limits make sure an abandoned session eventually signs out. In live, the same settings come from a Group Policy on the pool's OU; on dev, set them locally.

1. Run gpedit.msc.
2. Go to Computer Configuration → Administrative Templates → Windows Components → Remote Desktop Services → Remote Desktop Session Host → Session Time Limits.
3. Set time limit for disconnected sessions: Enabled, 30 minutes.
4. End session when time limits are reached: Enabled.
5. Optional: Set time limit for active but idle Remote Desktop Services sessions, for example 2 hours.

6.8 Make sure BitLocker is off

Windows 11 can turn on device encryption by itself. Sysprep refuses to run on an encrypted disk, and the clones can't use it anyway.

manage-bde -status C:
# If "Protection Status" is On, or "Conversion Status" isn't "Fully Decrypted":
manage-bde -off C:
# Prevent it switching back on:
Set-ItemProperty 'HKLM:\SYSTEM\CurrentControlSet\Control\BitLocker' -Name PreventDeviceEncryption -Value 1 -Type DWord

Wait for decryption to finish (manage-bde -status C: shows Fully Decrypted) before going on.

6.9 Optional: optimise for VDI

An optimisation tool such as the Omnissa OS Optimization Tool turns off background tasks, visual effects and scheduled jobs that waste CPU across many desktops. Run it last, after all software is installed, and keep a note of the template you applied.

7. Install software

Install the applications this pool needs. Install them for all users (per-machine) where the installer offers a choice.

Microsoft 365 Apps (Office)

Office in a pool must use Shared Computer Activation. Otherwise each new desktop uses up one of a user's five activations.

1. Download the Office Deployment Tool from Microsoft and extract it to C:\ODT.
2. Save this as C:\ODT\vdi.xml:

   <Configuration>
     <Add OfficeClientEdition="64" Channel="MonthlyEnterprise">
       <Product ID="O365ProPlusRetail">
         <Language ID="en-gb" />
         <ExcludeApp ID="Groove" />
         <ExcludeApp ID="Lync" />
       </Product>
     </Add>
     <Property Name="SharedComputerLicensing" Value="1" />
     <Property Name="FORCEAPPSHUTDOWN" Value="TRUE" />
     <Updates Enabled="FALSE" />
     <Display Level="None" AcceptEULA="TRUE" />
   </Configuration>

3. Run:

   cd C:\ODT
   .\setup.exe /configure vdi.xml

   It finishes silently after several minutes.
4. Don't sign in to Office in the master. On dev without licences, Office runs unlicensed, which is fine for testing.

8. Add the unattend file

The unattend file answers every Windows setup question on each clone, so a new desktop goes straight to the sign-in screen. Store it in the master so every version uses it.

1. Open Notepad as administrator.
2. Paste the following and save as C:\Windows\System32\Sysprep\unattend.xml. Set Save as type to All files so Notepad doesn't add .txt.

<?xml version="1.0" encoding="utf-8"?>
<unattend xmlns="urn:schemas-microsoft-com:unattend"
          xmlns:wcm="http://schemas.microsoft.com/WMIConfig/2002/State">
  <settings pass="specialize">
    <component name="Microsoft-Windows-Shell-Setup" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <!-- Random temporary name; SDE VDI renames the clone afterwards -->
      <ComputerName>*</ComputerName>
      <TimeZone>GMT Standard Time</TimeZone>
    </component>
    <component name="Microsoft-Windows-TerminalServices-LocalSessionManager" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <fDenyTSConnections>false</fDenyTSConnections>
    </component>
    <component name="Microsoft-Windows-TerminalServices-RDP-WinStationExtensions" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <UserAuthentication>1</UserAuthentication>
    </component>
    <component name="Networking-MPSSVC-Svc" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <FirewallGroups>
        <FirewallGroup wcm:action="add" wcm:keyValue="RemoteDesktop">
          <Active>true</Active>
          <Group>Remote Desktop</Group>
          <Profile>all</Profile>
        </FirewallGroup>
      </FirewallGroups>
    </component>
  </settings>
  <settings pass="oobeSystem">
    <component name="Microsoft-Windows-International-Core" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <InputLocale>0809:00000809</InputLocale>
      <SystemLocale>en-GB</SystemLocale>
      <UILanguage>en-US</UILanguage>
      <UserLocale>en-GB</UserLocale>
    </component>
    <component name="Microsoft-Windows-Shell-Setup" processorArchitecture="amd64"
               publicKeyToken="31bf3856ad364e35" language="neutral" versionScope="nonSxS">
      <OOBE>
        <HideEULAPage>true</HideEULAPage>
        <HideLocalAccountScreen>true</HideLocalAccountScreen>
        <HideOEMRegistrationScreen>true</HideOEMRegistrationScreen>
        <HideOnlineAccountScreens>true</HideOnlineAccountScreens>
        <HideWirelessSetupInOOBE>true</HideWirelessSetupInOOBE>
        <ProtectYourPC>3</ProtectYourPC>
      </OOBE>
      <TimeZone>GMT Standard Time</TimeZone>
    </component>
  </settings>
</unattend>

Shut the master down: Stop-Computer. This is the end of the master build.

9. Release a template version

To keep the master reusable, you sysprep a copy of it. Do this for v1 and for every later version.

1. With the master shut down, select it and choose Snapshots → Take Snapshot. Name it v1 and add a description of what's in this version. You can return to it if a later update goes wrong.
2. Right-click the master → Clone.
   • Mode: Full Clone.
   • VM ID: 9001; Name: gold-w11-office-v1.
   • Target storage: your template storage (section 3).
   • On a cluster, Target node: the node the template should live on.
3. On the new VM, open Hardware → Network Device → Edit and tick Disconnect. This stops it fetching updates or clashing with the master's name during sysprep.
4. Start it, open the Console and sign in as vdiadmin.
5. In an elevated PowerShell window, run sysprep:

   C:\Windows\System32\Sysprep\sysprep.exe /generalize /oobe /shutdown /mode:vm /unattend:C:\Windows\System32\Sysprep\unattend.xml

   The VM shuts itself down after a minute or two. If it stays on with an error, see Troubleshooting.
6. Don't start it again. Starting it would use up the generalised state, and you'd have to clone and sysprep again.
7. Prepare its hardware:
   • Network Device → Edit: untick Disconnect. Clones inherit this setting.
   • Both CD/DVD drives → Edit: Do not use any media.
   • Options: check that QEMU Guest Agent is Enabled.
8. On its Summary page:
   • Add the tag sde-gold.
   • In Notes, record the version, the date and what changed.
9. Right-click it → Convert to template.

The template gold-w11-office-v1 is ready. This is the name you choose in the SDE VDI admin UI.

10. Test the template

Do what SDE VDI will do, by hand, once.

1. Right-click the template → Clone. Mode: Linked Clone; Name: W11-TEST-001. Start it.
2. Watch the Console. It shows Getting ready, may restart once, then stops at the sign-in screen without asking any setup questions. This normally takes 2–4 minutes.
3. The clone's Summary shows an IP address, which confirms the guest agent works.
4. Rename it through the guest agent, the same way SDE VDI does. In the Proxmox node Shell, replace <vmid> with the clone's ID:

   qm guest exec <vmid> -- powershell -NoProfile -Command "Rename-Computer -NewName W11-TEST-001 -Force -Restart"

   The clone restarts.
5. From a PC on the same network, connect with Remote Desktop to the clone's IP as vdiuser. Check that the computer name is W11-TEST-001 (run hostname) and that your applications open.
6. Sign out. Then delete the test clone: stop it, then right-click → Remove.

11. Updating the image later

1. Start the master (w11-office-master), not a template.
2. Run Windows Update and add or update software.
3. Check that BitLocker is still off (6.8).
4. Shut it down.
5. Follow section 9 again with the next version: snapshot v2, full clone to gold-w11-office-v2, sysprep, convert to template.
6. In the SDE VDI admin UI, publish v2 to the pool. Desktops on v1 are replaced as their users sign out.
7. Delete the v1 template once no pool uses it and no desktops are still based on it. Proxmox refuses to delete a template that still has linked clones.

12. Troubleshooting

13. Final checklist

Before entering the template's name in the SDE VDI admin UI, check that:

• It is a template named gold-<os>-<variant>-v<N> and tagged sde-gold.
• All of its disks (main, EFI, TPM) are on storage that supports linked clones.
• The QEMU Guest Agent option is enabled, and a test clone shows its IP in Proxmox.
• A test clone boots to the sign-in screen without any setup questions.
• Renaming through qm guest exec works.
• RDP with NLA works (dev: as vdiuser).
• The network device is connected and the CD drives are empty.
• BitLocker is off; sleep and hibernation are off.
• The session time limits are set (dev: local policy; live: GPO on the pool OU).
• Office, if installed, uses Shared Computer Activation.
• The master VM is shut down, and has a snapshot for this version.
